GJPFQH
- PRODUCT DETAIL
Indoor cabling fiber optic cable
Applications:
The kind of cable is suitable for the occasion of multi-way transmission between instrument and communication equipments.
Characteristics:
Lighter and small diameter, flame retardant , separated easily and excellent performance of softness;
High strength of aramid yarn strength member, excellent performance of tensile strength resistance;
Low smoke halogen - micro tube structure makes construction and maintenance conveniently.
Operating Temperature:-20℃～﹢70℃
Transmission Performance
|
The Type Of The Fiber
|
62.5μm(OM1)
850nm/1300nm
|
50μm(OM2)
850nm/1300nm
|
50μm(OM3)
850nm/1300nm
|
SM
1310nm/1550nm
|
|
Attenuation Of Maximum Value(dB/km)
|
3.5/1. 5
|
3.5/1. 5
|
3.5/1. 5
|
0. 4/0. 3
|
|
Attenuation Of Typical Value(dB/km)
|
3.5/1. 5
|
3.0/1. 0
|
3.0/1. 0
|
0. 38/0. 25
|
Note:Other types of fiber can be provided according to the customer’s demands.
GJPFQH
Product Structure:
Product Description:
GJPFQH(Microbeam tube, Aramid yarn strengh member, LSZH sheath)
Standards:
YD/T 1258. 4-2005 Indoor optical fiber cable series multi-core optical cable
Technical Parameters(Typical Value):
|
Fiber Count
|
The micro tube diameter
(mm)
|
Specifications
(mm)
|
Weight (kg/km)
|
Tensile(N)
Long Short term term
|
Crush(N)
Long Short term term
|
Bending Radius(mm)
Static Dynamic
|
|
|
|
|
12
|
0.95
|
5.1
|
28
|
250
|
500
|
300
|
1000
|
10D
|
20D
|
|
24
|
1.2
|
5.9
|
35
|
250
|
500
|
300
|
1000
|
10D
|
20D
|
|
36
|
1.2
|
6.4
|
41
|
250
|
500
|
300
|
1000
|
10D
|
20D
|
|
48
|
1.4
|
6.2
|
40
|
250
|
500
|
300
|
1000
|
10D
|
20D
|
|
72
|
1.4
|
6.9
|
48
|
250
|
500
|
300
|
1000
|
10D
|
20D
|
|
96
|
1.4
|
7.5
|
55
|
250
|
500
|
300
|
1000
|
10D
|
20D
|
|
144
|
1.4
|
8.5
|
70
|
250
|
500
|
300
|
1000
|
10D
|
20D
|
Note 1.D refers to the cable diameter;
2.The relevant technical Parameters can be adjusted according to the customer’s demands;
3.PVC and other material can be used as sheath according to the customer’s demands.
